一、設備規格及主要技術參數

1.1 Production line specifications 0.4-3.0×1250mm

1.2開卷寬度範圍500-1500mm

1.3材料厚度0.4-3.0mm

1.4 框架材質Q235

1.5最大卷重10T

1.6鋼捲內徑508-610mm

1.7 Outer diameter of steel coil ≤1700mm

1.8 生產線速度55-58m/min

1.9 Cutting frequency 25-28 sheets (1000×2000mm shall prevail)

1.10 切割長度範圍500-6000mm

1.11 Sizing accuracy ±0.5/mm

1.12 Diagonal accuracy ±0.5/mm

1.13 Total power ≈85kw (normal working power 75kw)

1.14 放捲方向面向控制台從左向右

1.15 Unit area ≈25m×6.0m (used as standard)

1.16電源380v/50hz/3相（或自訂）

2. 和裝置成分
