Simple slitting line for multiple materials

Simple slitting line for multiple materials, without pit. This unit is specially for round steel coil, which is divided into several strips by disc blade, and then rolled into required strip by equipment. The mechanical equipment, shearing process, operating system and accessories are described below.

ceiling bar roll forming machine
china purlin roll forming machine exporter
rolling door roll forming machine
seam lock roll forming machine
speed 70m/min drywall roll forming machine
standing seam profile roll forming machine
tube mill production line
upright rack roll forming machine
inquire now
Product Detail
- Materials: Cold rolled sheet, galvanized sheet, aluminium sheet, ect.
- The thickness ：0.5mm-2.0mm, max width:800mm
- The number of blade:2-10 pcs, and the available length of shear shaft is 750mm
- OD of decoiler : 2000m
- ID of decoiler 508mm
- capacity of decoiler: 10Ton
This slitting line is suitable for dividing coils with a thickness of 0.5-2.5mm and a width of 500-800mm into strip steel coils, the narrowest not less than 130mm.
1. The cable length is 20m, no pit, no PLC, and it is driven by the stopper and the frequency converter, which is convenient and simple to install and operate.
2. Starting at 100m/min, the winding diameter will increase and the speed will become faster
1.5*500mm model is a hot sale, cheap, cost-effective, suitable for customers with lower budgets.
1. With high production capacity and low power consumption, it can be used by itself and can also sell finished strip steel.
2. The whole linecan be loaded in 2 small containers, and the freight is cheap.
3. The machine is adjusted and tested beforedelivery, saving raw materials.
Supply PLC adjust guide and video,
1. Provide machine test video and pictures of sample.
2. Yingyee hasexperienced engineers know how to deal with installation and other issues.
3. Provide operation manuals, circuit drawings, foundation drawings, and installation drawings.
