Supermarket shelf back panel ມ້ວນເຄື່ອງກອບເປັນຈໍານວນ

ເຄື່ອງນີ້ສາມາດເຮັດໃຫ້ກະດານຫລັງແລະຊັ້ນຂອງຊັ້ນວາງຂອງສັບພະສິນຄ້າ, Gondula.

china forming machine
ເຄື່ອງກອບເປັນຈໍານວນ
forming machines
steel forming machine
ສອບຖາມໃນປັດຈຸບັນ

ລາຍລະອຽດຜະລິດຕະພັນ

ການປະມວນຜົນ:

Coil loading (manual) → uncoiling → leveling → feeding (servo) → angle punching / logo punching → cold roll forming → cutting forming → discharging Read More About steel forming machine

Eອຸປະກອນ ອົງປະກອບ

ບໍ່	ຊື່ອົງປະກອບ	ແບບຈໍາລອງແລະຂໍ້ກໍາຫນົດ	ຕັ້ງ	ຂໍ້ສັງເກດ
1	ເຄື່ອງຊັກຜ້າ	T-500	1
2	ເຄື່ອງປັບລະດັບ	HCF-500	1	ເຄື່ອນໄຫວ
3	ເຄື່ອງປ້ອນ Servo	NCF-500	1	ໃຊ້ສອງເທົ່າ
4	ລະບົບ punching	ປະເພດສີ່ໄປສະນີຫຼາຍສະຖານີ	1	ໄຮໂດລິກ
5	ມ້ວນເຄື່ອງກອບເປັນຈໍານວນ	ປະເພດການປັບໄວ Cantilever	1	ການຄວບຄຸມຄວາມຖີ່
6	ເຄື່ອງຕັດແລະພັບ	ປະເພດການຕິດຕາມ	1	ການປະສົມປະສານ
7	ຕາຕະລາງຮັບ	ປະເພດມ້ວນ	1
8	ລະບົບໄຮໂດຼລິກ	ຄວາມໄວສູງ	2
9	ລະບົບຄວບຄຸມໄຟຟ້າ	PLC	2
10	ລະບົບແປງ	ປະເພດມ້ວນ	1	ສໍາລັບກອງທຶນ 1

supermarket shelf back panel roll forming machine

--------------------------------------------------------------------------------------------------

Basicspecification

No.	Items	Spec:
1	ວັດສະດຸ	1. Thickness: 0.6mm 2. Input width: max. 462mm 3. material: Cold rolled steel strip; yield limit σs≤260Mpa
2	Power supply	380V, 60Hz, 3 phase
3	Capacity of power	1. Total power: about 20kW 2. Punchine system power: 7.5kw 3. Roll forming machine power: 5.5kw 4. Track cutting machine power: 5kw
4	ຄວາມໄວ	ຄວາມໄວສາຍ: 0-9m / min (ລວມທັງ punching) ຄວາມໄວການສ້າງ: 0-12m / min
5	ນ້ຳມັນໄຮໂດລິກ	46#
6	ນ້ຳມັນເກຍ	18# Hyperbolic gear oil
7	ຂະໜາດ	Approx.(LWH) 20m×2m×2m
8	ຢືນຂອງ rollers	Roll forming machine for Fundo 2F: 17 rollers One Extra roller Fundo 1F: 12 rollers
9	ວັດສະດຸຂອງ rollers	Cr12, quenched HRC56°-60°
10	ຄວາມຍາວຂອງ workpiece ມ້ວນ	ຜູ້ໃຊ້ການຕັ້ງຄ່າຟຣີ
11	Cut style	Hydraulic Tracking cut
