Quadratröhre Millen Schweessmaschinn
Eis Solid State hf Welded Pipe & Tube Line mat der neier Technologie, treffen héich Effizienz Output, liicht operéiert a stabil Lafenleistung, och déi komplett Tube Mill Linn meet a high level automation. This high Solid state hf welding for Square tube mill with excellent design, selected high precision durable roller under strictly quenching , high performance cutting saw, complete machine body with heat treatment, accurate fabrication, precise assembly. The Solid state hf welding for Square tube mill performance has reached the international welded tube standard. This tube mill series outer diameter range can be from Φ7mm to Φ 50.8mm and wall thickness of 0.2~2.0mm,all these size tubes are produced with large output, best quality and high precision.Our customized machines are also can be used for different processed material and meet nearly all applications.
| Spezifizéierung vun HighSquaretube Mill Welding Machine |
| Modell |
Tube O.D. (mm) |
Wanddicke (mm) |
Geschwindegkeet (m/min) |
HF Power (Kw) |
Mainmotor (Kw) |
| JJ-12 |
φ7-16 |
0.2-0.5 |
30-100 |
60 |
15 |
| JJ-16 |
φ8-25 |
0.3-1.0 |
30-90 |
60 |
22 |
| JJ-25 |
φ8-30 |
0.4-1.3 |
30-90 |
100 |
37 |
| JJ-28 |
φ10-38 |
0.5-1.5 |
30-80 |
100 |
45 |
| JJ-32 |
φ13-50.8 |
0.6-2.0 |
20-90 |
100 |
75 |
