10-15m / min gemeinsam Rouleau Dier Maschinn

Zwou Zorte Rouleau Dier Rouleau administrativ Maschinn, 20-30m / min Torrist Typ Maschinn an 10-15m / min Mauer Panel gemeinsam Typ Maschinn. Dës 10-15m / min Maschinn huet kuerz Liwwerung Zäit a bëlleg Präis.

roller shutter door machine price
roller shutter door roll forming machine price
roller shutter door roll forming machine supplier
froen elo

Produit Detailer

1. D'Maschinn huet einfach Operatioun an niddereg Ausfall Taux

2. with straightening part, the slat is no distorted, and the finished product good

3. D'hydraulesch Statioun, déi am Maschinnkierper installéiert ass, spuert Plaz a Klengvolumen, niddereg Fracht

4. PLC and electrical is made in china.

5.The Geschwindegkeet ass 10-15m / min, entsprécht d'Bedierfnesser vun der Produktioun

6. Kann Muster Roller derbäi, (ongeféier 600 $)

3 Tonnen manuell decoiler

Inner dia: Ø440mm– Ø560mm

Max Input fidderen: 600mm

Kapazitéit: 3Tonnen

Material Füttern a Féierung

Leedung System besteet aus e puer Rollen, an d'Breet tëscht hinnen konnt duerch d'manuell Rollen kontrolléieren.

Formen Deel

1. Matching material: color plate，Galvanized steel

2. Material thickness range: 0.4mm-0.8mm

3. Main motor power: 5.5kw

4. Hydraulic power: 3.0kw

5. Feeding width 140mm

6. Forming speed: 10-15m /min

7. Quantity of stands: 15 rollers

8. Shaft Material and diameter: ￠50mm, 45# steel .

9.Tolerance: 3mm+/-1.0mm

10.Way Of Drive: 1.0 inch single chain driving

11.Controlling system: PLC system

12.Material of rollers: 45# steel ,heat treatment and chromed

13.Material of cutter blade: Cr 12 mould steel with quenched treatment HRC58-62

14.Voltage: 380V/ 3phase/ 50 Hz (as customer require）

15.Gréisst vun der Rollformmaschinn:

about 4. 3 m*1.0m*1.5m (L*W*H)

Hydraulesch System

Et gëtt kontrolléiert duerch Zännrad Uelegpompel. Nodeems Dir den hydraulesche Ueleg an den hydraulesche Uelegtank fëllt, fiert d'Pompel d'Cuttermaschinn fir d'Schneidaarbecht unzefänken.

Match Ausrüstung: De System enthält eng Rei vun hydraulesch Tank, eng Rei vun hydraulesch Ueleg Pompel, zwee hydraulesch Päifen.an zwee Sätze vun elektromagnetism Krunn.

Kraaft vun der Uelegpompel: 3kw Hydraulesch Ueleg: 40#

PLC Kontroll

Automatesch Längtmiessung Automatesch Quantitéitmessung

Computer benotzt fir Längt & Quantitéit ze kontrolléieren. Maschinn

wäert automatesch op d'Längt schneiden an ophalen wann déi néideg Quantitéit erreecht gëtt

Hydraulesch Ausschneiden

1.Cutting motion: The main machine automatically stops and then cutting. After the cutting, the main machine will automatically start.

2.Material of blade: CR12with heat treatment

3.Length measuring: Automatic length measuring

Roller shutter door machine
