    Basic Info

    Model No.:YY- -stm—001

    Control System:PLC

    Delivery Time:30 Days

    Warranty:12 Months

    Material Of Cutting Blade:Cr12

    Cutting Mode:Servo Tracking Cutting

    Type:Steel Frame & Purlin Machine

    After Service:Engineers Available To Service Machinery Overseas

    Voltage:380V/3Phase/50Hz Or At Your Request

    Forming Speed:0-45m/min(include Punching)

    Way Of Driven:Gear

    Additional Info

    Packaging:NUDE

    Productivity:200 sets/year

    Brand:YY

    Transportation:Ocean

    Place of Origin:Hebei

    Supply Ability:200 sets/year

    Certificate:CE/ISO9001

    HS Code:84552210

    Port:Tianjin Xingang

    Product Description

    high speed stud and track Making machine

    our machine is the world’s leader in manufacturing Industrial Level high speed Stud and Track making machine with a proven track record so strong that 100% of the world`s largest steel stud producers use YINGYEE roll forming equipment. Our machine with high speed ,the speed is about 45m/min. our stud and track making machine with high quality .if you interest .pls contact us. we will send you more detail .







    Working process:

    Working process

    Decoiler – Feeding guide – Straighteing – Main roll forming machine – PLC control system – Servo tracking cutting – Receiving table



    Technical parameters:



    Raw material PPGI, GI, Aluminum coils
    Material thickness range 0.3-1mm
    Forming speed 45m/min(include punching)
    Rollers 12 rows
    Material of forming rollers Cr12
    Shaft diameter and material 40mm, material is 45#steel
    Controlling system PLC
    Cutting mode Servo tracking cutting
    Material of cutting blade Cr12 mould steel with quenched treatment
    Voltage 380V/3Phase/50Hz or at your requirement
    Main motor power 5.5KW
    Hydraulic station power 3KW
    Way of driven Gear

    Pictures of machine:

    Stud And Track Machine From Yingyee0013Stud And Track Machine From Yingyee0008Stud And Track Machine From Yingyee0010

    Stud And Track Machine From Yingyee17

    Stud and track keel roll forming machine

    Stud and track keel roll forming machine



    Company information:

    YINGYEE MACHINERY AND TECHNOLOGY SERVICE CO.,LTD

    YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor formal the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment. Our products were sold to more than 20 countries already. Also included US and Germany. Main product :

    • Roof roll forming machine
    • Roller Shutter Door Roll Forming Machine
    • C and Z purlin roll forming machine
    • Downpipe Roll Forming Machine
    • Light Keel Roll Forming Machine
    • Shearing Machine
    • Hydraulic decoiler
    • Bending machine
    • Slitting machine

    FAQ:

    Training and Installation :
    1. We offer installation service local in paid, reasonable charge.
    2. QT test is welcome and professional.
    3. manual and using guide is optional if no visiting and no installation.


    Certification and after service:

    1. Match the technology standard, ISO producing certification
    2. CE certification
    3. 12 months warranty since the delivery. Board.


    Our advantage:

    1. Short delivery period
    2. Effective communication
    3. Interface customized.

    Looking for ideal High Speed Track Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Automatic Stud Machine are quality guaranteed. We are China Origin Factory of Light Keel Roll Forming Machine. If you have any question, please feel free to contact us.

    Product Categories : Light Keel Roll Forming Machine > Stud And Track Light Keel Forming Machine
