Guardrail roll forming machine for two waves and three waves as option, the thickness for the guardrail highway roll forming machine is from 2mm to 4mm.
Guardrail highway roll forming machine:
The thickness of 2mm is mostly used for national highways and driven by chain. The thickness of 4mm is mostly used for highway and driven by gearbox.
It can be equipped with a double-neck decoiler with a max load of 10 tons, which is convenient for uncoil.
Use 2 motors by 22kw, with big power. , shaft diameter is 110mm, roller material is GCR15 with high hardness and long service life.
Adopt pre-punching and pre-cutting technology, high efficiency and saving raw materials
Fully automatic production line, PLC adjustment and control. The process is mature, the production is stable, and the error is small.
Equipped with pre-cutting, saving materials, the length of the finished product is consistent, and the precision is high. Pre-punching is mould punching, and the punching position is accurate. The broken waste will slide down the holes on both sides for easy recycling.
The gear box is matched with universal joint transmission, which has strong power, heavy bearing, faster speed and more stable.
