Good price horizontal arch span forming machine, forming and bending seperately. Need about 4-5 workers to carry the semi-finished products from forming to bending part.
For the machine, we have total 4 size can make, and total 10 types shape as optional.
Take the example of horizontal 914-610 type
Size: |
About 8900mm × 2250mm × 2300mm |
Total Weight: |
about 13000KG |
Main Motor Power: |
forming power is 5.5kw bending power is 4.0kw cutting power is 4.0kw conical power is 1.5kw+1.5kw |
Working Speed: |
Straight sheet: 15m/min Arch sheet: 13m/min Sewing: 10m/min |
Material of rollers: |
45# steel, quenched HRC 58-62 |
Material of roller shafts: |
45# steel, adjusted |
Material of cutting blade: |
Cr12 , 1Mov |
PLC Type: |
Omron |
Step of rollers: |
13 steps |
Feeding Width: |
914mm |
Effective Width: |
610mm |
The depth of the groove: |
203mm |
Thickness of the coil: |
0.6-1.6mm |
Operating factor of the panel: |
66.7% |
Proper span: |
7-38m |
